產品型號 | 額定電壓kv | 額定機械負荷kn | 結構高度mm | 絕緣距離mm | 最小公稱爬電距離mm | 大傘徑絕緣子直徑mm | 1min工頻耐受電壓（有效值）kv | 雷電沖擊耐受電壓（峰值）KV |
FXBW4-12/70 | 12 | 70 | 390 | 200 | 4500 | 123/98 | 42 | 95 |
FXBW4-15/70 | 15 | 70 | 445 | 225 | 620 | 98 | 50 | 105 |
FXBW4-22/70 | 22 | 70 | 480 | 270 | 744 | 130/94 | 65 | 125 |
FXBW4-24/70 | 24 | 70 | 480 | 280 | 635 | 98 | 68 | 130 |
FXBW4-28/70 | 28 | 70 | 660 | 450 | 1200 | 144/116 | 95 | 230 |
FXBW4-33/70 | 33 | 70 | 660 | 450 | 1200 | 144/116 | 95 | 230 |
FXBW4-35/70 | 35 | 70 | 660 | 450 | 1200 | 144/116 | 95 | 230 |
FXBW4-36/70 | 36 | 70 | 660 | 450 | 1200 | 144/116 | 95 | 230 |
